Zirconia cement

Zircocem C-9 is a zircon based, non-corrosive ceramic adhesive potting compound. The cement when set has very high strength, with an adhesive strength of 36 kilograms per centimetres squared, and is also dispensable. Our Zirconia cement has excellent mechanical strength and outstanding chemical and thermal shock resistance. These advanced materials have the ability to withstand temperatures in excess of 1500^oC.

The Zirconia cement product range we offer, is made from selected quality materials, binders, additives and chemicals exhibiting typical characteristics such as high adhesion, high temperature resistance, thermal and electrical insulation, etc.

Advantanges

• Non-corrosive
• Cures at room temperature
• Excellent mechanical strength
• Improved moisture resistance when mixed with specialty MR liquid
• Dispensable

main applications

• Halogen Lamp Fixing
• Embedding electrical heating elements
• Embedding wire wound resistors
• Sealing cartridge heaters
• Sealing infrared heaters

This Zirconia cement is also ideal to adhere glass to glass, glass to ceramic, ceramic to ceramic, glass to metal, ceramic to metal, etc.

preparation

Mix Zircocem C-9 with water in ratio 4 parts powder to 1 part water by weight, alternatively mix with specialty MR liquid in same ratio and apply using trowel, brush or spray. Allow to cure at room temperature for around 24 hours at 25^oC Temperature. Also curing time depends on thickness.

Typical properties:
Dielectric Strength: 1200 -1250 volts/mm.
Volume Resistivity @ 25° C : - 10⁷ to 10⁹ ohm.cm
Adhesive Strength: 36 Kgs/cm²
Service temperature: >1500^oC
